Description
Key Specifications:
– Model: SUN-50K-SG01HP3-EU-BM4
– Type: Three-Phase Hybrid Solar Inverter
– Max AC Output Power: 50,000W
– Peak Power (Off-Grid): 55,000W
– Max AC Current: 75.8A
Technical Highlights:
– PV Input Voltage: 450-850V
– Max DC Input Power: 65,000W
– 2+2+2+2 MPPT Tracker Configuration
– Battery Voltage Range: 160-800V
– Lithium-Ion Battery Compatible
Performance Features:
– Maximum Efficiency: 97.60%
– MPPT Efficiency: >99%
– Power Factor: 0.8 leading to 0.8 lagging
– Grid Frequency: 50/60Hz
Protection Systems:
– Anti-islanding Protection
– Lightning Protection
– Insulation Resistance Detection
– Residual Current Monitoring
Installation Details:
– IP65 Rating
– Operating Temperature: -40°C to 60°C
– Wall-Mounted
– Dimensions: 527W × 894H × 294D mm
– Weight: 75 kg
